Overview of BharatBenz 4023T

Gross Combination Weight (GCW) 40200 Kg
Axle Configuration 4x2
Engine
  • DE175BSIV
  • SCR Technology
Power (Max.) 235 HP@2200 rpm
Torque (Max.) 850 Nm@1200-1600 rpm
Transmission 9 speed manual (9F+1R)
Warranty
  • 4 years / 4 Lakh km on driveline
  • 2 years unlimited km on vehicle
Service Interval 1,00,000 Km (Oil change) - Optional

Engine & Performance of BharatBenz 4023T

Engine
  • DE175BSIV
  • SCR Technology
Fuel Injection System Unitised fuel injection
Engine Displacement 6372 cc
Engine Cylinders 6
Power (Max.) 235 HP@2200 rpm
Torque (Max.) 850 Nm@1200-1600 rpm
Clutch
  • Single dry plate, 430 mm dia
  • With clutch booster
Transmission 9 speed manual (9F+1R)
Gearbox G131, Synchromesh gears
Gradeability 26.17%
Max Speed 80 Kmph
Emission Norms Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity
  • 290 Litres
  • Additional 200 Litres (Optional)
  • Ad-Blue Tank: 60 Litres
Electricals / Battery 2X12V,150 Ah

Design & Configuration of BharatBenz 4023T

Gross Combination Weight (GCW) 40200 Kg
Kerb Weight 6855 Kg
Cabin Type Sleeper cabin
Cabin Tilt mechanism Tiltable Cabin
Chassis Frame Channel section with cross members
Axle Configuration 4x2
Front Axle Reverse Elliot Type
Rear Axle
  • IR440, Fully floating
  • Single reduction hypoid gear
  • With differential lock
Front Suspension
  • Parabolic leaf springs
  • With telescopic shock absorbers
Rear Suspension Semi elliptical leaf with auxiliary springs
Anti-Roll Bar Front only
Tyres 11R20-16PR
Wheelbase 3600 mm
Turning Circle Diameter 13.1 m
Ground Clearance 264 mm
Overall Length 6040 mm
Overall Width 2490 mm
Overall Height 2960 mm
Front Overhang 1460 mm
Rear Overhang 980 mm
Chassis Depth 288 mm
Chassis Flange width 70 mm
Chassis Thickness 9 mm

Features & Comfort in BharatBenz 4023T

Cabin Suspension Fully suspended
Steering Type Power Steering
Steering Adjustment Tilt and telescopic
Driver Seat Type 6 way adjustable
Air Conditioner (A/C)
  • Blower (Standard)
  • HVAC (Optional)
Openable Quarter Ventilation Glass No
Instrument Cluster
  • Digital with indicators for:
  • Reverse gear indication
  • Distance to empty
Power Windows No
Automatic Transmission No
Cruise Control Yes
Additional
  • Variable green band
  • PTO (Optional)
  • Lockable storage space below co-driver seat

Safety in BharatBenz 4023T

Service Brakes Air Brakes, dual line
Parking Brakes Pneumatic operated hand control valve
ABS Yes
Anti-Roll Bar Front only
Differential Lock Yes
Seat Belts Yes
Fog Light Yes
Tubeless Tyres No
