Commercial Vehicles in India

  • Mahindra Loadking Optimo LD 4 Tyre

Quick Search

Overview of Mahindra Loadking Optimo LD 4 tyre

GVW 6255 Kg
Engine
  • 2.5 Lit MDI CRDe
  • Fuel Smart Technology
Power (Max.) 70 HP@3200 rpm
Torque (Max.) 200 Nm@1400-2200 rpm
Axle Configuration 4x2
Vehicle Configuration
  • Cabin and chassis
  • Cabin with load body options
Load Body Options
  • High Side Deck
  • Drop Side Deck
Loading Span
  • 10.2 ft
  • 14 ft
Warranty
  • 3 Years / 3 Lakh Km on driveline
  • 1 Year / 1 Lakh Km on vehicle
Service Interval 20000 Km
Additional
  • Fuel smart options
  • Load
  • Empty

Engine & Performance of Mahindra Loadking Optimo LD 4 tyre

Engine
  • 2.5 Lit MDI CRDe
  • Fuel Smart Technology
Fuel Injection System Common Rail
Engine Displacement 2500 cc
Engine Cylinders 4
Power (Max.) 70 HP@3200 rpm
Torque (Max.) 200 Nm@1400-2200 rpm
Clutch 240 mm dia
Transmission 5 speed manual (5F+1R)
Gearbox BD 30
Gradeability 22%
Max Speed 80 Kmph
Emission Norms Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity 60 Litres

Design & Configuration of Mahindra Loadking Optimo LD 4 tyre

GVW 6255 Kg
Kerb Weight 1980 Kg (CBC)
Vehicle Configuration
  • Cabin and chassis
  • Cabin with load body options
Load Body Options
  • High Side Deck
  • Drop Side Deck
Loading Span
  • 10.2 ft
  • 14 ft
Cabin Type Day cab
Cabin Tilt mechanism NA
Axle Configuration 4x2
Front Suspension Semi elliptical leaf springs
Rear Suspension Semi elliptical leaf springs
Tyres
  • 8.25x16-16 PR
  • 4+1 tyres
Wheelbase
  • 2500 mm
  • 3320 mm
Turning Circle Diameter
  • 11.9 m (2500 wb)
  • 14.6 m (3320 wb)
Overall Length
  • 4840 mm (2500 wb)
  • 5970 mm (3320 wb)

Features & Comfort in Mahindra Loadking Optimo LD 4 tyre

Cabin Suspension NA
Steering Type Power Steering
Steering Adjustment Tilt and telescopic
Driver Seat Type 2 way adjustable
Air Conditioner (A/C) No
Openable Quarter Ventilation Glass No
Power Windows No
Music System No
Mobile Charging Point Yes
Bottle Holder Yes
Automatic Transmission No
Cruise Control No

Safety in Mahindra Loadking Optimo LD 4 tyre

Service Brakes Hydraulic brakes
Differential Lock No
Seat Belts Yes
Fog Light No
Tubeless Tyres No
