Eicher Pro 3016 truck specifications

Rate This Vehicle

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers for this month

Download Eicher Pro 3016 Truck Brochure

Check out the Eicher Pro 3016 Truck PDF brochure at TrucksBuses.com with all features and specifications.

Key Details of Eicher Pro 3016 Truck

Power

165

GVW

16200 Kg

Fuel

Diesel

Engine

3760 cc

Cylinders

Key Specifications of Eicher Pro 3016 Truck

Engine
Configuration

Engine
E494 CRS 4 cyl 4 valve
SCR Technology
With Volvo group EMS 3.0
Fuel Injection System
Common rail
Engine Displacement
3760 cc
Engine Cylinders
4
Power
165 HP@2600 rpm
Torque
520 Nm @ 1400-1600 rpm
Clutch
352 mm dia
With foot rest
Transmission
7 speed manual (7F+1R)
Hybrid gear shift lever
AMT (Optional)
Gearbox
ET 50 S7
Gradeability
23.6%
Max Speed
80 Kmph
Emission Norms Compliance
BSIV
Fuel Type
Diesel
Fuel Tank Capacity
Diesel : 190 / 395 Litres
Adblue tank : 20 Litres
Electricals Battery
12V, 100 Ah

GVW
16200 Kg
Vehicle Configuration
Cabin and chassis
Cabin with load body options
Loading Span
20 ft
24 ft
31.5 ft
Cabin Type
Sleeper cabin
Cabin Tilt mechanism
Manually tiltable
Chassis Frame
Domex frame
Axle Configuration
4x2
Rear Axle
Banjo type
Front Suspension
Parabolic leaf spring
Rear Suspension
Semi-elliptical leaf springs
With helper leaf springs
Anti Roll Bar
Front only
Tyres
10R20-16 PR
Radial tyres
6+1 tyres
Wheelbase
4490 mm
5490 mm
6690 mm
Turning Circle Diameter
14.3 m (4490 wb)
17.2 m (5490 wb)
Ground Clearance
258 mm
Load Body Width
2343 mm
Chassis Depth
230 mm
Chassis Flange width
76 mm
Chassis Thickness
6 mm

Eicher Pro 3016 Truck Specification Highlights

Check all the Eicher Pro 3016 specifications on TrucksBuses in the table above The main driveline of this Eicher truck includes a 3760 cc 4 cylinder engine that produces a maximum power of 165 HP and a torque of 520 Nm It gets mated to 7 speed manual (7F+1R), Hybrid gear shift lever, AMT (Optional), ET 50 S7 gearbox A gross weight of 16200 kg and multiple configurations allows the owner to carry multiple kinds of goods as per requirement There are multiple features in this Eicher truck for enhancing driver comfort Other Eicher Pro 3016 truck specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the tables above.

Eicher Pro 3016 Truck Brochure

Download Eicher Pro 3016 Truck brochure online. Check out the Eicher Pro 3016 Truck PDF brochure at TrucksBuses.com with all features and specifications.

Frequently Asked Questions on Eicher Pro 3016 Truck

What is Eicher Pro 3016 gradeability ?

Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Eicher Pro 3016 is 23.6%.

Eicher Pro 3016 is available in which all body options ?

Eicher Pro 3016 is available in multiple body options of

What is Eicher Pro 3016 tyre size and number of wheels in this truck ?

The tyre size of Eicher Pro 3016 is 10R20-16 PR# Radial tyres# 6+1 tyres

What is the type of brakes offered in Eicher Pro 3016 ?

Eicher Pro 3016 comes with Air brakes# With auto slack adjuster

What is the warranty offered in Eicher Pro 3016 ?

Eicher Pro 3016 truck comes with a standard warranty of 4 years unlimited km on engine and gearbox# 2 years unlimited km on vehicle

What is the latest Eicher Pro 3016 price in India ?

Eicher Pro 3016 price starts from Rs 0 . The 2023 price of Eicher Pro 3016 can vary slightly from state to state and city to city.

What is the Eicher Pro 3016 GVW tonnage capacity ?

GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Eicher Pro 3016 GVW is 16200 Kg

What is the Eicher Pro 3016 payload capacity ?

Payload defines the loading capacity of any truck. The payload of Eicher Pro 3016 is

What is Eicher Pro 3016 power and torque ?

In terms of performance, Eicher Pro 3016 produces a maximum power of 165 HP@2600 rpm and a maximum torque of 520 Nm @ 1400-1600 rpm

What is the engine capacity of Eicher Pro 3016 ?

Eicher Pro 3016 comes with 4 cylinder E494 CRS 4 cyl 4 valve# SCR Technology# With Volvo group EMS 3.0 engine and the engine displacement is 3760 cc

What is the fuel tank capacity of Eicher Pro 3016 ?

Eicher Pro 3016 comes with Diesel fuel option and its fuel tank capacity is Diesel : 190 / 395 Litres# Adblue tank : 20 Litres

What is the gearbox and transmission type in Eicher Pro 3016 ?

Eicher Pro 3016 comes with a 7 speed manual (7F+1R)# Hybrid gear shift lever# AMT (Optional) transmission along with a 352 mm dia# With foot rest clutch
