Volvo 9400 14.5M Bus Specifications

Rate This Vehicle

From ₹ 135 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price
 Don't miss out on the best discount offers for this month

Key Details of Volvo 9400 14.5M Bus

Power
410
GVW
22000 Kg
Fuel
Diesel
Engine
10800 cc
Cylinders
6
Trucksbuses.com
Trucksbuses.com

Key Specifications of Volvo 9400 14.5M Bus

  • Engine
    D11C 410
    Turbocharged, Intercooled
  • Fuel Injection System
    Unit injection
  • Engine Displacement
    10800 cc
  • Engine Cylinders
    6
  • Engine Location
    Rear
  • Power
    410 HP@1600-1900 rpm
  • Torque
    1900 Nm@900-1400 rpm
  • Transmission
    12 speed (12F+4R)
    With automatic Gear changing system
  • Gearbox
    I-Shift, AT2412D
  • Gradeability
    53.30%
  • Max Speed
    80 Kmph
  • Emission Norms Compliance
    BSIV
  • Fuel Type
    Diesel
  • Fuel Tank Capacity
    600 Litres
    2 tanks of 300+300 Litres
  • Electricals Battery
    2x12V, 165 Ah
    Alternator: 150 A
  • GVW
    22000 Kg
  • Seating Layout
    2x2
  • Seating Capacity
    55+D
  • Body Structure
    Galvanized tubular structure
  • Passenger Door Type
    Pneumatically operated
  • Floor Type
    Boiling water proof ply + FR grade
  • Chassis Frame
    All steel, ladder type
  • Axle Configuration
    6x2
  • Front Axle
    Rigid type
  • Rear Axle
    Rigid type
    Additional tag axle
  • Front Suspension
    Independent air suspension
    Electronically controlled
  • Rear Suspension
    Air suspension
  • Anti Roll Bar
    Front, tag and rear axle
  • Tyres
    295/80 R 22.5
    Tubeless radial
    8+1 tyres
  • Wheelbase
    8350 mm
  • Turning Circle Diameter
    23.1 m
  • Ground Clearance
    209 mm
  • Overall Length
    14500 mm
  • Overall Width
    2600 mm
  • Overall Height
    3600 mm
  • Front Overhang
    2620 mm
  • Rear Overhang
    2830 mm
  • Front Track
    2054 mm
  • Rear Track
    1837 mm

Volvo 9400 14.5M Bus Specification Highlights

Check all the Volvo 9400 14.5M bus specifications here on TrucksBuses Gearbox matched with this engine is 12 speed (12F+4R), With automatic Gear changing system Volvo 9400 14.5M comes with a gross weight capacity of 22000 kg and length of 14500 mm For the comfortable journeys, independent air suspension, electronically controlled in front and air suspension in rear does the duty in this Volvo bus Other Volvo 9400 14.5M bus specifications like chassis, tyre, body width, turning circle dia, engine cc are available here in the tables on this page.

Frequently Asked Questions on Volvo 9400 14.5M Bus

Volvo 9400 14.5M bus GVW is 22000 Kg
Volvo 9400 14.5M bus comes with 6 cylinder D11C 410# Turbocharged, Intercooled engine and the engine displacement is 10800 cc
Volvo 9400 14.5M bus comes with a 12 speed (12F+4R)# With automatic Gear changing system transmission
Volvo 9400 14.5M bus comes with Diesel fuel option and its fuel tank capacity is 600 Litres# 2 tanks of 300+300 Litres
The tyre size of Volvo 9400 14.5M bus is 295/80 R 22.5# Tubeless radial# 8+1 tyres
In terms of performance, Volvo 9400 14.5M bus produces a maximum power of 410 HP@1600-1900 rpm and a maximum torque of 1900 Nm@900-1400 rpm
Volvo 9400 14.5M bus can be purchased in multiple seating options depending on requirement. The seating capacity of Volvo 9400 14.5M bus is 55+D seats
Volvo 9400 14.5M bus comes with Full-air Disc brakes# Electronic Braking System (EBS)# Electronic Stability Program (ESP)
The monthly EMI of any bus depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Volvo 9400 14.5M bus is expected to be around Rs Not Available for a 5 year period
