What is the Eicher Pro 6054 GCW tonnage capacity ?

GCW of any tractor trailer is the sum total of empty kerb weight and the payload it can carry. Eicher Pro 6054 GVW is

Eicher Pro 6054 BS6 tractor trailer specifications

Rate This Vehicle

From ₹ 40.71-41.21 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers for this month

Download Eicher Pro 6054 Tractor Trailer Brochure

Check out the Eicher Pro 6054 Tractor Trailer PDF brochure at TrucksBuses.com with all features and specifications.

Key Details of Eicher Pro 6054 Tractor Trailer

Power

260

GVW

54000 Kg

Fuel

Diesel

Engine

7698 cc

Cylinders

Key Specifications of Eicher Pro 6054 Tractor Trailer

Engine
Configuration

Engine
VEDX8
Fuel Injection System
Common Rail
Engine Displacement
7698 cc
Engine Cylinders
6
Power
260 HP@2200 rpm
Torque
1000 Nm@1000-1700 rpm
Clutch
430 mm dia
With clutch booster
Transmission
9 speed (9F+1R)
Gearbox
ET 140 S9
Gradeability
21%
Max Speed
80 Kmph
Emission Norms Compliance
BS6
Fuel Type
Diesel
Fuel Tank Capacity
Diesel: 350 Litres
Ad Blue: 50 Litres
Polymer tank
Electricals Battery
24V, 120 Ah

Gross Combination Weight
54000 Kg
Cabin Type
Sleeper cabin
Cabin Tilt mechanism
Hydraulically tiltable
Chassis Frame
Domex frame
Axle Configuration
4x2
Front Axle
Forged I Beam, Reverse Elliot Type
Rear Axle
Banjo type, Single reduction
FDR 4.8
Front Suspension
Parabolic leaf springs
With telescopic shock absorbers
Rear Suspension
Semi elliptical leaf springs
Tyres
11R20
6+1 tyres
Wheelbase
3200 mm
Ground Clearance
220 mm
Overall Length
5455 mm
Overall Width
2560 mm
Chassis Depth
285 mm
Chassis Flange width
76 mm
Chassis Thickness
6 mm

Eicher Pro 6054 Tractor Trailer Specification Highlights

We are here to describe the engine performance and body configuration of the Eicher Pro 6054 tractor-trailer. Latest Eicher Pro 6054 has a 6-cylinder engine of 7698 cc displacement that can produce a power of 260 horsepower and a high-end torque of 1000 Nm. The power transmission of Eicher Pro 6054 is managed by a 9-speed gearbox system. The Eicher Pro 6054 tractor follows BS6 emission norms which has a fuel tank capacity of 350 liters. This Eicher Pro tractor-trailer gives a gradeability of 21%. This trailer has a hydraulically tiltable sleeper cabin with an axle configuration of 4x2. The front suspension has parabolic leaf springs with telescopic shock absorbers while the rear suspension has semi-elliptical leaf springs. The wheelbase of this Eicher Pro 6054 trailer is 3200 mm and its tyre size is 11R20. It gives a ground clearance of 220 mm. Some other configurational features are mentioned above in the table.

Eicher Pro 6054 Tractor Trailer Brochure

Download Eicher Pro 6054 Tractor Trailer brochure online. Check out the Eicher Pro 6054 Tractor Trailer PDF brochure at TrucksBuses.com with all features and specifications.

Frequently Asked Questions on Eicher Pro 6054 Tractor Trailer

What is the EMI of Eicher Pro 6054 ?

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Eicher Pro 6054 is expected to be around Rs Not Available for a 5 year period
