Tata Prima 3138.K Tipper Specifications

 Don't miss out on the best discount offers for this month

Key Details of Tata Prima 3138.K Tipper

31000 Kg
8898 cc

Key Specifications of Tata Prima 3138.K Tipper

  • Engine
    Cummins ISLe
  • Fuel Injection System
    Common Rail
  • Engine Displacement
    8898 cc
  • Engine Cylinders
  • Power
    370 HP@2100 rpm
  • Torque
    1550 Nm@1200-1400 rpm
  • Clutch
    Single dry plate, 430 mm dia
  • Transmission
    9 speed manual (8F+1CR+1R)
  • Gearbox
    Eaton ES 15409A
  • Gradeability
    Crawler gear: 74%
    First gear: 50%
  • Max Speed
    66 Kmph
  • Emission Norms Compliance
  • Fuel Type
  • Fuel Tank Capacity
    260 Litres
  • GVW
    31000 Kg
  • Vehicle Configuration
    Cabin with Box body
    Cabin with Scoop body
  • Cabin Type
    Day cab
  • Cabin Tilt mechanism
    Tiltable cabin
  • Chassis Frame
    Ladder type with riveted/bolted cross members
  • Axle Configuration
  • Front Axle
    Forged I beam
    Twin steerable axles
  • Rear Axle
    Planetary hub reduction, Fully floating
    Tata RA-210 HR-T
  • Front Suspension
    Parabolic leaf springs
  • Rear Suspension
    Bogie suspension
  • Anti Roll Bar
    Front and Rear
  • Tyres
    12x24 - 18PR
  • Wheelbase
    5250 mm
  • Turning Circle Diameter
    14.6 m
  • Ground Clearance
    358 mm
  • Overall Length
    9257 mm
  • Overall Width
    2550 mm
  • Overall Height
    3670 mm
  • Chassis Depth
    320 mm
  • Chassis Flange width
    90 mm
  • Chassis Thickness
    8 mm
  • Load Body Dimensions
    23 Cu.M Box body
    19 Cu.M Scoop body

Tata Prima 3138.K Tipper Specification Highlights

Check all the Tata Prima 3138.K specifications on TrucksBuses in the table above. The main driveline of this Tata tipper includes a 6 cylinder Cummins ISLe engine that produces a maximum power of 370 HP and a torque of 1550 Nm. It is matched with 9 speed manual (8F+1CR+1R), Eaton ES 15409A gearbox. A gross weight of 31000 kg and multiple body configurations allows the owner to carry multiple kinds of loads as per requirement, in this Tata dumper. Tata Prima 3138.K tipper comes with a day cab with multiple utility features for driver comfort. Other Tata Prima 3138.K tipper specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the table above.

Frequently Asked Questions on Tata Prima 3138.K Tipper

Tata Prima 3138.K price starts from Rs 0. The 2023 price of Tata Prima 3138.K can vary slightly from state to state and city to city.
GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Tata Prima 3138.K GVW is 31000 Kg
Tata Prima 3138.K comes with 6 cylinder Cummins ISLe engine and the engine displacement is 8898 cc
In terms of performance, Tata Prima 3138.K produces a maximum power of 370 HP@2100 rpm and a maximum torque of 1550 Nm@1200-1400 rpm
Tata Prima 3138.K comes with Diesel fuel option and its fuel tank capacity is 260 Litres
Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Tata Prima 3138.K is Crawler gear: 74%# First gear: 50%.
Tata Prima 3138.K comes with a 9 speed manual (8F+1CR+1R) transmission along with a Single dry plate, 430 mm dia clutch
The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Tata Prima 3138.K is expected to be around Rs Not Available for a 5 year period
The tyre size of Tata Prima 3138.K is 12x24 - 18PR# Mining
Tata Prima 3138.K tipper comes with a standard warranty of 4 Years / 5000 Hrs on driveline# 2 Years / 2000 Hrs on vehicle
