What is the engine capacity of Eicher Pro 6035 TM tipper?

Eicher Pro 6035 TM comes with 6 cylinder VEDX8 engine and the engine displacement is 7698 cc

What is the warranty offered in Eicher Pro 6035 TM tipper ?

Eicher Pro 6035 TM tipper comes with a standard warranty of

Eicher Pro 6035 TM BS6 Tipper Specifications

Rate This Vehicle

From ₹ 54.09-55.10 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers for this month

Download Eicher Pro 6035 TM Transit Mixer Brochure

Check out the Eicher Pro 6035 TM Transit Mixer PDF brochure at TrucksBuses.com with all features and specifications.

Key Details of Eicher Pro 6035 TM Transit Mixer

Power

260

GVW

35000 Kg

Fuel

Diesel

Engine

7698 cc

Cylinders

Key Specifications of Eicher Pro 6035 TM Transit Mixer

Engine
Configuration

Engine
VEDX8
Fuel Injection System
Common Rail
Engine Displacement
7698 cc
Engine Cylinders
6
Power
260 HP@2200 rpm
Torque
1000 Nm@1000-1700 rpm
Clutch
395 mm dia
With clutch booster
Transmission
9 speed (8F+1CR+1R)
Gearbox
ET 140 S9
Gradeability
39%
Max Speed
80 Kmph
Emission Norms Compliance
BS6
Fuel Type
Diesel
Fuel Tank Capacity
Diesel: 220 Litres
Ad Blue: 33 Litres
Electricals Battery
24V, 120 Ah

GVW
35000 Kg
Vehicle Configuration
Cabin chassis with PTO
Cabin with body
Load Body Options
9 / 10 Cu.M drum
Cabin Type
Day cab
Cabin Tilt mechanism
Hydraulically tiltable
Chassis Frame
Domex frame
Axle Configuration
8x4
Front Axle
Forged I Beam, Reverse Elliot Type
Twin steer axle
Rear Axle
Banjo type, Single reduction
RAR 5.29
Front Suspension
Parabolic leaf springs
Rear Suspension
Bogie suspension
Anti Roll Bar
Front only
Tyres
11x20 - Nylon
Wheelbase
5285 mm
Turning Circle Diameter
18.6 m
Ground Clearance
252 mm
Front Track
2085 mm
Rear Track
1875 mm
Chassis Depth
300 mm
Chassis Flange width
90 mm
Chassis Thickness
7 mm
With 5 mm stiffener

Eicher Pro 6035 TM Transit Mixer Specification Highlights

Check all the Eicher Pro 6035 TM specifications on TrucksBuses in the table aboveThe main driveline of this Eicher tipper includes a 6 cylinder VEDX8 engine that produces a maximum power of 260 HP and a torque of 1000 NmIt is matched with 9 speed (8F+1CR+1R), ET 140 S9 gearbox A gross weight of 35000 kg and multiple body configurations allows the owner to carry multiple kinds of loads as per requirement, in this Eicher dumperEicher Pro 6035 TM tipper comes with a day cab with multiple utility features for driver comfort Other Eicher Pro 6035 TM tipper specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the table above.

Eicher Pro 6035 TM Transit Mixer Brochure

Download Eicher Pro 6035 TM Transit Mixer brochure online. Check out the Eicher Pro 6035 TM Transit Mixer PDF brochure at TrucksBuses.com with all features and specifications.

Frequently Asked Questions on Eicher Pro 6035 TM Transit Mixer

What is Eicher Pro 6035 TM tyre size and number of wheels in this truck ?

The tyre size of Eicher Pro 6035 TM is 11x20 - Nylon

What is the Eicher Pro 6035 TM GVW tonnage capacity ?

GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Eicher Pro 6035 TM GVW is 35000 Kg

What is Eicher Pro 6035 TM power and torque ?

In terms of performance, Eicher Pro 6035 TM produces a maximum power of 260 HP@2200 rpm and a maximum torque of 1000 Nm@1000-1700 rpm

What is the type of brakes offered in Eicher Pro 6035 TM ?

Eicher Pro 6035 TM comes with Air brakes# With APDA

What is the fuel tank capacity of Eicher Pro 6035 TM ?

Eicher Pro 6035 TM comes with Diesel fuel option and its fuel tank capacity is Diesel: 220 Litres# Ad Blue: 33 Litres

What is Eicher Pro 6035 TM gradeability ?

Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Eicher Pro 6035 TM is 39%.

What is the latest Eicher Pro 6035 TM price in India ?

Eicher Pro 6035 TM price starts from Rs 54.09-55.10 Lakh*. The 2023 price of Eicher Pro 6035 TM can vary slightly from state to state and city to city.

What is the gearbox and transmission type in Eicher Pro 6035 TM tipper ?

Eicher Pro 6035 TM comes with a 9 speed (8F+1CR+1R) transmission along with a 395 mm dia# With clutch booster clutch

Eicher Pro 6035 TM is available in which all body options ?

Eicher Pro 6035 TM is available in 9 / 10 Cu.M drum body

What is the EMI of Eicher Pro 6035 TM tipper ?

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Eicher Pro 6035 TM is expected to be around Rs Not Available for a 5 year period
