BharatBenz 3523R BS6 truck specifications

Name: BharatBenz 3523R
Brand: BharatBenz
SKU: P-N-bpdVy4

Rate This Vehicle

From ₹ 44.49-44.96 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers for this month

Download BharatBenz 3523R Truck Brochure

Check out the BharatBenz 3523R Truck PDF brochure at TrucksBuses.com with all features and specifications.

Key Details of BharatBenz 3523R Truck

Power

241

GVW

35000 Kg

Fuel

Diesel

Engine

7200 cc

Cylinders

Key Specifications of BharatBenz 3523R Truck

Engine
Configuration

Engine
OM 926
Fuel Injection System
Unitised fuel injection pump
Engine Displacement
7200 cc
Engine Cylinders
6
Power
241 HP
Torque
850 Nm
Clutch
395 mm dia
With clutch booster
Transmission
6 speed (6F+1R)
Gearbox
G85, Synchromesh
Gradeability
18.50%
Max Speed
80 Kmph
Emission Norms Compliance
BS6
Fuel Type
Diesel
Fuel Tank Capacity
Diesel: 380 / 200 Litres
Ad Blue: 60 / 51 Litres
With diesel anti-theft strain
Electricals Battery
24V, 120/130 Ah

GVW
35000 Kg
Payload
26.3 Tons (28 ft CBC)
Vehicle Configuration
Cabin and chassis
Cabin with load body
Loading Span
26 ft
28 ft
32 ft
Cabin Type
Sleeper cabin
Cabin Tilt mechanism
Hydraulically tiltable
Chassis Frame
Channel section with cross members
Axle Configuration
8x2
Front Axle
IF 7.0 Reverse Elliot Type
Rear Axle
Axle 1:IR440-11
Axle 2: IT- 10
RAR 5.875
Pusher Lift axle
Front Suspension
Front axle: Parabolic leaf spring with shock absorbers
Pusher axle: Pneumatic Lift
Rear Suspension
Balancer type semi elliptical leaf springs
Anti Roll Bar
Optional
Tyres
11R20 or 295/90R20
295/80 R22.5 Tubeless
12+1 tyres
Wheelbase
5775 mm
6375 mm
Turning Circle Diameter
21.6 m (5775 wb)
23.7 m (6375 wb)
Ground Clearance
238 mm
Overall Length
10492 mm (5775 wb)
11092 mm (6375 wb)
11192 mm (6375 wb compact sleeper)
Overall Width
2490 mm
Overall Height
2960 mm
Front Overhang
1485 mm
Rear Overhang
2557 / 3457 mm
Chassis Depth
286 mm
Chassis Flange width
70 mm
Chassis Thickness
8 mm

BharatBenz 3523R Truck Specification Highlights

TrucksBuses provides clear information about the latest specifications of BharatBenz 3523R truck. If we discuss the engine, it offers a powerful OM 926 engine with a displacement of 7200 cc which producing a high-end torque of 850 Nm and 241 HP power. The power transmission of latest BharatBenz 3523R is managed by a 6-speed G85 and synchromesh gearbox. The gradeability of 12 chakka BharatBenz 3523R is 18.50% and hands a maximum speed of 80 kilometers per hour. It runs on diesel fuel with a large fuel tank capacity following BS6 emission norms. You can get this latest BharatBenz 3523R truck in two variants, first is a cabin with chassis and another is a cabin with load body. It also has three loading span sizes 26 feet, 28 feet and 32 feet etc, and an axle configuration of 8x2. BharatBenz 3523R has a hydraulically tiltable sleeper cabin that enhances its comfortability a lot.

BharatBenz 3523R Truck Brochure

Download BharatBenz 3523R Truck brochure online. Check out the BharatBenz 3523R Truck PDF brochure at TrucksBuses.com with all features and specifications.

Frequently Asked Questions on BharatBenz 3523R Truck

What is the fuel tank capacity of BharatBenz 3523R ?

BharatBenz 3523R comes with Diesel fuel option and its fuel tank capacity is Diesel: 380 / 200 Litres# Ad Blue: 60 / 51 Litres# With diesel anti-theft strain

BharatBenz 3523R is available in which all body options ?

BharatBenz 3523R is available in multiple body options of 10492 mm (5775 wb)# 11092 mm (6375 wb) #11192 mm (6375 wb compact sleeper)

What is the EMI of BharatBenz 3523R ?

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of BharatBenz 3523R is expected to be around Rs 77679 for a 5 year period
