Overview of Tata LP 1112 : CityRide 45 Seater

Seating Capacity 45+D
Engine 497 TCIC CRDI
Power (Max.) 123 HP@2400 rpm
Torque (Max.) 400 Nm@1300-1500 rpm
GVW 12670 Kg
Suitable Applications Staff
Warranty
  • 3 Years / 3 Lakh Km on driveline
  • 1.5 Years / 1.5 Lakh Km on body
Service Interval
  • 20,000 Km (Short route)
  • 40,000 Km (Long route)

Engine & Performance of Tata LP 1112 : CityRide 45 Seater

Engine 497 TCIC CRDI
Fuel Injection System Common rail
Engine Displacement 3783 cc
Engine Cylinders 4
Engine Location Front
Power (Max.) 123 HP@2400 rpm
Torque (Max.) 400 Nm@1300-1500 rpm
Clutch 330 mm dia
Transmission 5 speed manual (5F+1R)
Gearbox GBS 40
Max Speed 107 Kmph
Emission Norms Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity 160 Litres
Electricals / Battery
  • 12 V, 150 Ah
  • 65 Amps

Design & Configuration of Tata LP 1112 : CityRide 45 Seater

GVW 12670 Kg
Seating Layout 3X2
Seating Capacity 45+D
Body Structure Galvanized tubular structure
Passenger Door Type One jack-knife type
Floor Type Anti-skid vinyl flooring
Chassis Frame Ladder type with cross members
Axle Configuration 4x2
Front Axle Forged I section, Reverse Elliot type
Front Suspension
  • Semi-elliptical leaf springs
  • With telescopic shock absorbers
Rear Suspension
  • Semi-elliptical leaf springs
  • With telescopic shock absorbers
Anti-Roll Bar Front and Rear
Tyres
  • 8.25x20 - 16 PR
  • 6+1 tyres
Wheelbase 4855 mm
Turning Circle Diameter 19 m
Ground Clearance 240 mm
Overall Length 9100 mm
Overall Width 2570 mm
Overall Height 3100 mm
Internal Height (Saloon) 1900 mm
Front Overhang 1335 mm
Rear Overhang 2910 mm

Features & Comfort in Tata LP 1112 : CityRide 45 Seater

Steering Type Power Steering
Steering Adjustment Rigid
Instrument cluster
  • Analog
  • With LED display
Automatic Transmission No
Air Conditioner (A/C) No
Openable Quarter Ventilation Glass Yes
Sun Visor Flap Type
Front Windshield Single piece laminated glass
Rear Windshield Single piece tempered glass
Side Windows Sliding glass
Hatrack Tubular
Passenger Seat Type High back seats
Arm Rests Available on front seats
AC Vents NA
Mobile Charging Point Yes
Saloon Light LED lights
Step Lamp Yes
Luggage Space Side luggage boot
Additional Digital clock in passenger saloon

Safety in Tata LP 1112 : CityRide 45 Seater

Service Brakes Air brakes
ABS Yes
Anti-Roll Bar Front and Rear
Grab Handle Available on each seat
Window Guardrail Yes
Guide/Grab Rail Yes
Driver Area Partition Partition with MS pipe
Door Alarm Yes
Emergency Exit
  • Breakable rear glass with hammer
  • Door at rear RH side
Roof Hatch No
Fire Extinguisher Yes
First Aid Box Yes
Peep Window Yes
Step Lamp Yes
Fog Light Provision
Tubeless Tyres No
Retarder No
Additional Reverse parking buzzer
