Key Details of Volvo FM 420 4x2 Tractor Trailer

Power
420
GVW
45500 Kg
Fuel
Diesel
Engine
12800 cc
Cylinders
6
Trucksbuses.com
Trucksbuses.com

Key Specifications of Volvo FM 420 4x2 Tractor Trailer

  • Engine
    12.8L Inline, Direct injection
  • Fuel Injection System
    Unitised fuel injection pump
  • Engine Displacement
    12800 cc
  • Engine Cylinders
    6
  • Power
    420 HP@1400-1800 rpm
  • Torque
    2100 Nm@800-1400 rpm
  • Clutch
    430 mm
    Push type single plate
  • Transmission
    12 speed (12F+4R)
  • Gearbox
    I-Shift Automatic
  • Emission Norms Compliance
    BS6
  • Fuel Type
    Diesel
  • Fuel Tank Capacity
    Diesel: 735 Litres
    Ad Blue: 64 Litres
  • Electricals Battery
    24 V, 170 Ah
  • Gross Combination Weight
    45500 Kg
  • Cabin Type
    Sleeper cabin
  • Cabin Tilt mechanism
    Hydraulically tiltable
  • Chassis Frame
    C channel section
  • Axle Configuration
    4x2
  • Rear Axle
    Single reduction solo axle
  • Front Suspension
    Parabolic leaf spring
  • Rear Suspension
    Air suspension with 3 driving levels
  • Tyres
    295/80 R22.5
  • Wheelbase
    3500 mm
  • Overall Length
    5690 mm
  • Overall Width
    2534 mm
  • Overall Height
    3030 mm
  • Chassis Depth
    300 mm
  • Chassis Flange width
    90 mm
  • Chassis Thickness
    8 mm

Volvo FM 420 4x2 Tractor Trailer Specification Highlights

Check all the Volvo FM 420 4x2 specifications on TrucksBuses in this section The main driveline of Volvo FM 420 4x2 includes a 6 cylinder 12.8L Inline, Direct injection engine that produces a maximum power of 420 HP and a torque of 2100 Nm It gets mated to 12 speed (12F+4R), I-Shift Automatic gearbox A gross weight of 45500 kg coupled with suitable trailer, allows the owner to carry multiple kinds of goods as per requirementVolvo FM 420 4x2 comes with a beautiful looking sleeper cabin with wide variety of utility features for driver comfort Other Volvo FM 420 4x2 specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available in the tables above.

Frequently Asked Questions on Volvo FM 420 4x2 Tractor Trailer

Volvo FM 420 4x2 comes with 6 cylinder 12.8L Inline, Direct injection engine and the engine displacement is 12800 cc
In terms of performance, Volvo FM 420 4x2 produces a maximum power of 420 HP@1400-1800 rpm and a maximum torque of 2100 Nm@800-1400 rpm
Volvo FM 420 4x2 comes with a 12 speed (12F+4R) transmission along with a 430 mm# Push type single plate clutch
Volvo FM 420 4x2 comes with Diesel fuel option and its fuel tank capacity is Diesel: 735 Litres# Ad Blue: 64 Litres
The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Volvo FM 420 4x2 is expected to be around Rs Not Available for a 5 year period
The tyre size of Volvo FM 420 4x2 is 295/80 R22.5
Volvo FM 420 4x2 comes with Air brakes# Electronic Brake System (EBS)
