Overview of Tata Prima 4938.P

Gross Combination Weight (GCW) 49000 Kg
Axle Configuration 6x4
Engine
  • Cummins ISLe 375
  • Direct Injection, Turbo-charged
Power (Max.) 370 HP@2100 rpm
Torque (Max.) 1550 Nm@1200-1400 rpm
Transmission 9 speed manual (8F+1CR+1R)

Engine & Performance of Tata Prima 4938.P

Engine
  • Cummins ISLe 375
  • Direct Injection, Turbo-charged
Fuel Injection System Common Rail
Engine Displacement 8898 cc
Engine Cylinders 6
Power (Max.) 370 HP@2100 rpm
Torque (Max.) 1550 Nm@1200-1400 rpm
Clutch
  • Single dry plate, 430 mm dia
  • Organic
  • With Clutch Booster
Transmission 9 speed manual (8F+1CR+1R)
Gearbox
  • Eaton ES-15409
  • 9F-Synchromesh
  • 1R- Constant mesh
Gradeability 31%
Max Speed 64 Kmph
Emission Norms Compliance BSIII
Fuel Type Diesel
Fuel Tank Capacity 400 Litres
Electricals / Battery
  • 2x12V, 150 Ah
  • Alternator: 90 Amps

Design & Configuration of Tata Prima 4938.P

Gross Combination Weight (GCW) 49000 Kg
Kerb Weight 9970 Kg
Cabin Type Sleeper cabin with 4 point suspension
Cabin Tilt mechanism Hydraulically tiltable- Electronic Control
Chassis Frame Channel section with cross members
Axle Configuration 6x4
Rear Axle
  • HRT 210 Hub Reduction Axle
  • RAR-6.492
Front Suspension Parabolic leaf springs
Rear Suspension Inverted Bogie Suspension
Tyres 11R20-16PR
Wheelbase 3890 mm
Turning Circle Diameter 14.22 m
Overall Length 7008 mm
Overall Width 2585 mm
Front Overhang 1720 mm
Chassis Depth 286 mm
Chassis Flange width 90 mm
Chassis Thickness 7 mm

Features & Comfort in Tata Prima 4938.P

Cabin Suspension Fully suspended
Steering Type Power Steering
Steering Adjustment Tilt and telescopic
Driver Seat Type
  • 6 way adjustable
  • With air suspension
Air Conditioner (A/C) Yes
Openable Quarter Ventilation Glass No
Instrument Cluster Digital with Fuel Mileage indicator
Telematics / GPS Tracking
  • Telematics unit as standard fitment
  • Service activation (Optional)
Automatic Transmission No
Cruise Control No

Safety in Tata Prima 4938.P

Service Brakes Air Brakes, dual line
ABS Yes
Differential Lock No
Seat Belts Yes
Fog Light Yes
Tubeless Tyres No
