Tata LPT 1512 CRX

LPT 1512 CRX is the new 15.8 Ton GVW Tata Truck in ICV category. Tata Motors Commercial Vehicles has introduced this new Tata 1512 LPT based on 4 cylinder engine platform to cater to rated load applications. This new Tata truck gets powered by famous 497 TCIC engine that produces 123 HP & 400 Nm of torque and comes with a standard clutch booster for comfortable drives. Tata LPT 1512 Truck precisely caters to mass market segment with higher rated payload. Bigger 9R20 tyres lead to class leading ground clearance of 245 mm in this new 6 wheeler Tata truck. Power steering along with tilt & telescopic adjustment, arm rest and utility features like bottle holder, Ultra comfort pack lead to fatigue less long drives in Tata LPT 1512 truck. A fuel tank capacity of 160 litres gives a class leading range without refuelling. Submit link below to know about Tata LPT 1512 truck price.

Overview of Tata LPT 1512 CRX

GVW 15800 Kg
Engine
  • 497 TCIC CRDI
  • EGR Technology
Power (Max.) 123 HP@2400 rpm
Torque (Max.) 400 Nm@1300-1600 rpm
Axle Configuration 4x2
Vehicle Configuration
  • Cabin and chassis
  • Cabin with load body options
Load Body Options
  • Fixed Side Deck
  • High Side Deck
Loading Span
  • 19 ft
  • 22 ft
Warranty 3 Years / 3 Lakh Km on driveline
Service Interval 40,000 Km (Oil change)

Engine & Performance of Tata LPT 1512 CRX

Engine
  • 497 TCIC CRDI
  • EGR Technology
Fuel Injection System Common Rail
Engine Displacement 3783 cc
Engine Cylinders 4
Power (Max.) 123 HP@2400 rpm
Torque (Max.) 400 Nm@1300-1600 rpm
Clutch
  • 330 mm dia
  • Booster assisted
Transmission 5 speed manual (5F+1R)
Gearbox GBS 40, Synchromesh type
Gradeability 25.4%
Max Speed 80 Kmph
Emission Norms Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity 160 Litres
Electricals / Battery 12V, 100 Ah

Design & Configuration of Tata LPT 1512 CRX

GVW 15800 Kg
Vehicle Configuration
  • Cabin and chassis
  • Cabin with load body options
Load Body Options
  • Fixed Side Deck
  • High Side Deck
Loading Span
  • 19 ft
  • 22 ft
Cabin Type Day cab
Cabin Tilt mechanism Manually tiltable
Chassis Frame Ladder type with cross members
Axle Configuration 4x2
Front Axle Forged I Beam, Reverse Elliot Type
Rear Axle Fully Floating, RA108R
Front Suspension
  • Semi-elliptical leaf springs
  • With telescopic shock absorbers
Rear Suspension Semi-elliptical leaf springs
Tyres
  • 9R20–16 PR
  • Radial tyres
  • 6+1 tyres
Wheelbase
  • 4200 mm
  • 4830 mm
Turning Circle Diameter 14.7 m
Ground Clearance 245 mm
Overall Length 8100 mm
Overall Height 3200 mm
Front Track 1800 mm
Chassis Depth 223 mm
Chassis Flange width 60 mm
Chassis Thickness 7 mm

Features & Comfort in Tata LPT 1512 CRX

Cabin Suspension No
Steering Type Power Steering
Steering Adjustment Tilt and telescopic
Driver Seat Type 6 way adjustable
Air Conditioner (A/C) No
Openable Quarter Ventilation Glass No
Instrument Cluster
  • Analog
  • With LED display
Telematics / GPS Tracking No
Power Windows No
Music System No
Mobile Charging Point Yes
Bottle Holder Yes
Automatic Transmission No
Cruise Control No
Additional
  • Digital clock
  • Ultra comfort pack

Safety in Tata LPT 1512 CRX

Service Brakes
  • Air brakes
  • With automatic slack adjustment
Parking Brakes
  • Graduated valve controlled spring brake
  • Acting on rear axle
Exhaust Brake Yes
ABS Yes
Differential Lock No
Seat Belts Yes
Reverse Parking Buzzer Yes
Fog Light Yes
Tubeless Tyres No
