Commercial Vehicles in India

  • Eicher Pro 5031

Quick Search

Overview of Eicher Pro 5031

GVW 31000 Kg
Engine
  • E694 CRS
  • i3 EGR Technology
Power (Max.) 192 HP@2400 rpm
Torque (Max.) 715 Nm@1200-1800 rpm
Axle Configuration 8x2
Vehicle Configuration
  • Face Cowl and chassis
  • Cabin and chassis
  • Cabin with load body options
Load Body Options
  • Fixed Side Deck
  • High side deck
Loading Span
  • With Cabin: 24 ft, 26 ft, 31 ft
  • With Cowl: 24 ft, 26 ft, 32 ft
Warranty 4 years / 4 Lakh km on driveline
Service Interval 60,000 Km (Oil change)
Additional Fuel coaching

Engine & Performance of Eicher Pro 5031

Engine
  • E694 CRS
  • i3 EGR Technology
Fuel Injection System Common Rail
Engine Displacement 5700 cc
Engine Cylinders 6
Power (Max.) 192 HP@2400 rpm
Torque (Max.) 715 Nm@1200-1800 rpm
Clutch
  • 380 mm dia
  • With clutch booster
Transmission 6 speed manual (6F+1R)
Gearbox ET 90 S6
Gradeability 20%
Max Speed 76 Kmph
Emission Norms Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity 415 Litres
Electricals / Battery 24V

Design & Configuration of Eicher Pro 5031

GVW 31000 Kg
Kerb Weight 7415 Kg (Cowl)
Vehicle Configuration
  • Face Cowl and chassis
  • Cabin and chassis
  • Cabin with load body options
Load Body Options
  • Fixed Side Deck
  • High side deck
Loading Span
  • With Cabin: 24 ft, 26 ft, 31 ft
  • With Cowl: 24 ft, 26 ft, 32 ft
Cabin Type Sleeper cabin
Cabin Tilt mechanism Manually Tiltable
Chassis Frame
  • C channel ladder type
  • Domex frame
Axle Configuration 8x2
Front Axle
  • Forged I Beam, Reverse Elliot Type
  • Twin steer axle
Rear Axle Fully floating
Front Suspension
  • Semi-elliptical leaf springs
  • With telescopic shock absorbers
Rear Suspension
  • Semi-elliptical leaf springs
  • With Bell crank mechanism
Anti-Roll Bar No
Tyres
  • 10x20-16 PR
  • 12+1 tyres
Wheelbase
  • 5590 mm
  • 6600 mm
Ground Clearance 252 mm
Overall Width 2450 mm
Front Overhang 1370 mm
Rear Track 1818 mm
Chassis Depth 285 mm
Chassis Flange width 76 mm
Chassis Thickness 6 mm

Features & Comfort in Eicher Pro 5031

Cabin Suspension Semi suspended
Steering Type Power steering
Steering Adjustment Tilt and telescopic
Driver Seat Type 4 way adjustable
Air Conditioner (A/C) No
Openable Quarter Ventilation Glass No
Instrument Cluster
  • Digital
  • With fuel coaching
Telematics / GPS Tracking No
Power Windows No
Music System No
Mobile Charging Point Yes
Bottle Holder No
Automatic Transmission No
Cruise Control Yes

Safety in Eicher Pro 5031

Service Brakes Air brakes
Parking Brakes
  • Full air hand operated brakes
  • Acting at rear wheels
Exhaust Brake Yes
ABS Yes
Anti-Roll Bar No
Differential Lock No
Seat Belts Yes
Reverse Parking Buzzer Yes
Fog Light No
Tubeless Tyres No
