Commercial Vehicles in India

  • Force Trax Cruiser

Quick Search

Overview of Force Trax Cruiser

Seating Capacity
  • 9+D
  • 12+D
  • 13+D
Power (Max.) 67 HP@3200 rpm
Torque (Max.) 175 Nm@1600-2400 rpm
GVW
  • 2875 Kg (9, 12 Seater)
  • 2950 Kg (13 Seater)
Warranty 3 Years / 3 Lakh Km
Service Interval 7500 Km
Additional 6 free services

Engine & Performance of Force Trax Cruiser

Engine FM 2.0 CR
Engine Displacement 1947 cc
Engine Cylinders 3
Power (Max.) 67 HP@3200 rpm
Torque (Max.) 175 Nm@1600-2400 rpm
Transmission 5 speed (5F+1R) Manual
Gearbox Synchromesh
Emission Norms Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity 63.5 Litres

Design & Configuration of Force Trax Cruiser

GVW
  • 2875 Kg (9, 12 Seater)
  • 2950 Kg (13 Seater)
Seating Capacity
  • 9+D
  • 12+D
  • 13+D
Axle Configuration 4x2
Front Axle Independent
Rear Axle Live Rigid
Front Suspension
  • Independent with solid torsion bar
  • With hydraulic telescopic shock absorbers
Rear suspension
  • Semi elliptical leaf springs
  • With hydraulic telescopic shock absorbers
Anti-roll bar Front only
Tyres 7.00 R 15
Wheelbase 3050 mm
Turning Circle Radius 6.3 m
Ground Clearance 210 mm
Overall Length 4832 mm
Overall Width 1660 mm
Overall Height 2055 mm
Front Overhang 707 mm
Rear Overhang 1075 mm

Features & Comfort in Force Trax Cruiser

Steering Type
  • Mechanical type
  • Power Steering (Optional)
Steering Adjustment No
Driver Seat Type Standard seat with high head rest
Passenger Seat Type Bench seats
Air Conditioner (A/C) No
Music System No
Mobile Charging Point Yes
Power Windows No

Safety in Force Trax Cruiser

Service Brakes
  • Front: Hydraulic Disc
  • Rear: Hydraulic Drum brakes with LSV
Parking Brakes Mechanical on rear wheels
Anti-Roll Bar Front only
Seat Belts Yes
Tubeless Tyres No
Fog Light No
Additional ABS (Optional)
