Tata Ultra T.12 BS6 truck specifications

Name: Tata Ultra T.12
Brand: Tata
SKU: P-N-f6eaQ3

Rate This Vehicle

From ₹ 23.07-24.44 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers for this month

Download Tata Ultra T.12 Truck Brochure

Check out the Tata Ultra T.12 Truck PDF brochure at TrucksBuses.com with all features and specifications.

Key Details of Tata Ultra T.12 Truck

Power

155

GVW

11990 Kg

Fuel

Diesel

Engine

3300 cc

Cylinders

Key Specifications of Tata Ultra T.12 Truck

Engine
Configuration

Engine
3.3L NG
Fuel Injection System
Common Rail
Engine Displacement
3300 cc
Engine Cylinders
4
Power
155 HP@2600 rpm
Torque
450 Nm@1400-2200 rpm
Clutch
330 mm dia
With clutch booster
Transmission
6 speed (6F+1R)
With cable shift
Gearbox
GBS 550 PTOP
Gradeability
26.80%
Max Speed
80 Kmph
Emission Norms Compliance
BS6
Fuel Type
Diesel
Fuel Tank Capacity
Diesel: 160 Litres
Ad Blue: 25 Litres

GVW
11990 Kg
Vehicle Configuration
Cabin and chassis
Cabin with load body
Load Body Options
Fixed Side Deck
High Side Deck
Loading Span
20 ft
22 ft
24 ft
Cabin Type
Day cab
Sleeper cabin (Optional)
Cabin Tilt mechanism
Manually tiltable
Chassis Frame
Ladder type with cross members
Axle Configuration
4x2
Front Axle
Forged I Beam, Reverse Elliot Type
Front Suspension
Parabolic leaf springs
With telescopic shock absorbers
Rear Suspension
Semi elliptical leaf springs
With auxiliary springs
Tyres
245/75 R 17.5
Tubeless Radial
6+1 tyres
Wheelbase
4920 mm
5600 mm
Turning Circle Diameter
15.2 m (20 ft body)
16.9 m (22 ft)
18.2 m (24 ft)
Ground Clearance
185 mm
Overall Width
2255 mm
Overall Height
2933 mm
Load Body Width
2117 mm

Tata Ultra T.12 Truck Specification Highlights

At this segment of specification of the Latest Tata Ultra T.12 truck which has an awesome engine performance and a well-balanced body configuration. The 6 wheeler Tata Ultra T.12 truck has a powerful engine displacement of 3300 cc and it produces a power of 155 horsepower along with a high-end torque of 450 Nm. The axle configuration of this 6 wheeler Tata Ultra truck is 4x2 and the load body size is 20 feet, 22 feet and 24 feet. The Ultra T.12 truck runs on diesel fuel having a large fuel tank capacity of 160 litres. This new 6 chakka Ultra T.12 truck follows BS6 OBD2 emissions norms. You will get cabin and chassis and a cabin with a box body in this 6 wheeler truck. The front suspension of this Tata Ultra truck has parabolic type leaf springs with hydraulic shock absorbers while the rear suspension comes with semi-elliptical leaf springs. Check the other specifications of Tata Ultra T.12 on the table above.

Tata Ultra T.12 Truck Brochure

Download Tata Ultra T.12 Truck brochure online. Check out the Tata Ultra T.12 Truck PDF brochure at TrucksBuses.com with all features and specifications.

Frequently Asked Questions on Tata Ultra T.12 Truck

What is the engine capacity of Tata Ultra T.12 ?

Tata Ultra T.12 comes with 4 cylinder 3.3L NG engine and the engine displacement is 3300 cc

What is the Tata Ultra T.12 GVW tonnage capacity ?

GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Tata Ultra T.12 GVW is 11990 Kg

What is Tata Ultra T.12 power and torque ?

In terms of performance, Tata Ultra T.12 produces a maximum power of 155 HP@2600 rpm and a maximum torque of 450 Nm@1400-2200 rpm

What is the fuel tank capacity of Tata Ultra T.12 ?

Tata Ultra T.12 comes with Diesel fuel option and its fuel tank capacity is Diesel: 160 Litres# Ad Blue: 25 Litres

What is Tata Ultra T.12 gradeability ?

Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Tata Ultra T.12 is 26.80%.

What is Tata Ultra T.12 tyre size and number of wheels in this truck ?

The tyre size of Tata Ultra T.12 is 245/75 R 17.5#Tubeless Radial# 6+1 tyres

What is the type of brakes offered in Tata Ultra T.12 ?

Tata Ultra T.12 comes with Air brakes# With auto slack adjuster

What is the latest Tata Ultra T.12 price in India ?

Tata Ultra T.12 price starts from Rs 23.07-24.44 Lakh* . The 2023 price of Tata Ultra T.12 can vary slightly from state to state and city to city.

What is the gearbox and transmission type in Tata Ultra T.12 ?

Tata Ultra T.12 comes with a 6 speed (6F+1R)# With cable shift transmission along with a 330 mm dia# With clutch booster clutch

What is the EMI of Tata Ultra T.12 ?

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Tata Ultra T.12 is expected to be around Rs 43429 for a 5 year period
