Overview of Tata Signa 4923.T CRe 12x2

GVW
  • 49000 Kg (max GVW with Tubeless tyres)
  • 45000 Kg (min GVW with Tube type tyres)
Engine
  • Cummins ISBe 5.9 CRDi
  • SCR Technology
Power (Max.) 229 HP@2500 rpm
Torque (Max.) 850 Nm@1200-1700 rpm
Axle Configuration 12x2
Vehicle Configuration
  • Cabin and chassis
  • Cabin with load body options
Load Body Options
  • Fixed Side Deck
  • High Side Deck
Loading Span
  • 29.5 ft
  • 31.5 ft
Warranty
  • 6 Years / 6 Lakh Km on driveline
  • 3 Years / 3 Lakh Km on vehicle
Service Interval 80,000 Km (Oil change)
Additional
  • Multi Drive Mode: Heavy, Light
  • Gear Shift Advisor

Engine & Performance of Tata Signa 4923.T CRe 12x2

Engine
  • Cummins ISBe 5.9 CRDi
  • SCR Technology
Fuel Injection System Common Rail
Engine Displacement 6700 cc
Engine Cylinders 6
Power (Max.) 229 HP@2500 rpm
Torque (Max.) 810 Nm@ 1000-1800 rpm
Clutch
  • 380 mm dia Organic
  • With clutch booster
Transmission 9 speed manual (9F+1R)
Gearbox G1150
Gradeability 19%
Max Speed 80 Kmph
Emission Norms Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity 300 Litres
Electricals / Battery 2x12V, 120 Ah

Design & Configuration of Tata Signa 4923.T CRe 12x2

GVW
  • 49000 Kg (max GVW with Tubeless tyres)
  • 45000 Kg (min GVW with Tube type tyres)
Kerb Weight 14000 Kg
Vehicle Configuration
  • Cabin and chassis
  • Cabin with load body options
Load Body Options
  • Fixed Side Deck
  • High Side Deck
Loading Span
  • 29.5 ft
  • 31.5 ft
Cabin Type Sleeper cabin
Cabin Tilt mechanism Hydraulically tiltable
Chassis Frame Ladder type with cross members
Axle Configuration 12x2
Front Axle
  • Forged I Beam, Reverse Elliot Type
  • Twin steer axle
Rear Axle
  • Single reduction type RA 110
  • RAR 6.14
Front Suspension
  • Parabolic leaf springs
  • With telescopic shock absorbers
Rear Suspension
  • Semi-elliptical leaf springs
  • With Bell crank mechanism
Anti-Roll Bar Front and Rear (Optional)
Tyres
  • 295/80 R22.5 (Tubeless)
  • 10R20-16 PR Tube (Optional)
  • 16+1 tyres
Wheelbase 6730 mm
Turning Circle Diameter 23.6 m
Ground Clearance 230 mm
Overall Length
  • 11400 mm
  • 11990 mm
Overall Width 2580 mm
Overall Height
  • 2950 mm (Cabin)
  • 3370 mm (HSD)
Front Overhang 1379 mm
Rear Overhang
  • 950 mm
  • 1510 mm
Chassis Depth 285 mm
Chassis Flange width 65 mm
Chassis Thickness 7 mm

Features & Comfort in Tata Signa 4923.T CRe 12x2

Cabin Suspension Semi suspended
Steering Type Power Steering
Steering Adjustment Tilt and telescopic
Driver Seat Type
  • 6 way adjustable
  • Mechanically suspended
Air Conditioner (A/C) Yes
Openable Quarter Ventilation Glass No
Instrument Cluster Digital
Telematics / GPS Tracking Telematics unit as standard fitment
Power Windows No
Music System Optional
Mobile Charging Point Yes
Bottle Holder Yes
Automatic Transmission No
Cruise Control No
Additional Gear Shift Advisor

Safety in Tata Signa 4923.T CRe 12x2

Service Brakes
  • Air brakes
  • With automatic slack adjuster
Parking Brakes
  • Graduated valve controlled spring brake
  • Acting on rear axle
Exhaust Brake Yes
ABS Yes
Anti-Roll Bar Front and Rear (Optional)
Differential Lock No
Seat Belts Yes
Reverse Parking Buzzer Yes
Fog Light No
Tubeless Tyres Optional
