Tata LPT 1918 Turbotronn 5L BS6 truck specifications

Name: Tata LPT 1918 Turbotronn 5L
Brand: Tata
SKU: P-N-GNxzs0

Tata LPT 1918 Turbotronn 5L Truck Images

Rate This Vehicle

From ₹ 25.21-26.41 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers for this month

Download Tata LPT 1918 Turbotronn 5L Truck Brochure

Check out the Tata LPT 1918 Turbotronn 5L Truck PDF brochure at TrucksBuses.com with all features and specifications.

Key Details of Tata LPT 1918 Turbotronn 5L Truck

Power

177

GVW

18500 Kg

Fuel

Diesel

Engine

5005 cc

Cylinders

Key Specifications of Tata LPT 1918 Turbotronn 5L Truck

Engine
Configuration

Engine
5L Turbotronn
Fuel Injection System
Common Rail
Engine Displacement
5005 cc
Engine Cylinders
4
Power
177 HP@2300 rpm
Torque
700 Nm@1000-1700 rpm
Clutch
380 mm dia
Transmission
6 speed (6F+1R)
Gearbox
GBS 750
Max Speed
80 Kmph
Emission Norms Compliance
BS6
Fuel Type
Diesel
Fuel Tank Capacity
365 Litres
365+365 Litres (32 ft)
Polymer tank
With anti-fuel theft

GVW
18500 Kg
Vehicle Configuration
Cowl with chassis
Loading Span
18 ft
20 ft
24 ft
32 ft
Cabin Type
Sleeper cabin option
Cabin Tilt mechanism
Hydraulically tiltable
Chassis Frame
Ladder type straight frame
Axle Configuration
4x2
Front Axle
Forged I Beam, Reverse Elliot Type
Rear Axle
Single reduction RA 1085RR
RAR 4.11
Front Suspension
Parabolic leaf springs
Rear Suspension
Semi elliptical leaf springs
Tyres
295/90R20 (Tube)
6+1 tyres
Wheelbase
4225 mm
4855 mm
5195 mm
6750 mm
Turning Circle Diameter
16.7 m
Overall Length
7380 mm (4225 wb)
9495 mm (5195 wb)
Overall Width
2440 mm
Front Overhang
1185 mm
Rear Overhang
1970 mm (4225 wb)
3115 mm (5195 wb)
Front Track
1933 mm
Rear Track
1809 mm
Chassis Depth
285 mm
Chassis Flange width
65 mm
Chassis Thickness
6 mm

Tata LPT 1918 Turbotronn 5L Truck Specification Highlights

On this page, you will get to know about the engine performance and body configuration of new Tata LPT 1918 Turbotronn. Tata 6 wheeler LPT 1918 truck offers a high-power 5L Turbontronn engine with an engine displacement of 5005 cc. The latest Tata LPT 1918 is controlled by a 6-speed power transmission gearbox. There are various driving comfort features in Tata 6 chakka LPT 1918 commercial vehicle as it is aided with a sleeper(optional) hydraulically tiltable mechanism cabin. The chassis of Tata LPT 1918 Turbotronn truck has a ladder-type straight frame. It also offers a variable-size wheelbase shown above and its chassis dimensions are 285 mm (depth), 65 mm (flange depth) and 6 mm (thickness). The front suspension of 6 wheeler Tata LPT 1918 Turbotronn truck has parabolic leaf springs and semi-elliptical leaf springs in the rear suspension.

Tata LPT 1918 Turbotronn 5L Truck Brochure

Download Tata LPT 1918 Turbotronn 5L Truck brochure online. Check out the Tata LPT 1918 Turbotronn 5L Truck PDF brochure at TrucksBuses.com with all features and specifications.

Frequently Asked Questions on Tata LPT 1918 Turbotronn 5L Truck

What is the Tata LPT 1918 Turbotronn 5L GVW tonnage capacity ?

GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Tata LPT 1918 Turbotronn 5L GVW is 18500 Kg

What is Tata LPT 1918 Turbotronn 5L power and torque ?

In terms of performance, Tata LPT 1918 Turbotronn 5L produces a maximum power of 177 HP@2300 rpm and a maximum torque of 700 Nm@1000-1700 rpm

What is the latest Tata LPT 1918 Turbotronn 5L price in India ?

Tata LPT 1918 Turbotronn 5L price starts from Rs 25.21-26.41 Lakh* . The 2023 price of Tata LPT 1918 Turbotronn 5L can vary slightly from state to state and city to city.

What is the gearbox and transmission type in Tata LPT 1918 Turbotronn 5L ?

Tata LPT 1918 Turbotronn 5L comes with a 6 speed (6F+1R) transmission along with a 380 mm dia clutch

What is the engine capacity of Tata LPT 1918 Turbotronn 5L ?

Tata LPT 1918 Turbotronn 5L comes with 4 cylinder 5L Turbotronn engine and the engine displacement is 5005 cc

What is the type of brakes offered in Tata LPT 1918 Turbotronn 5L ?

Tata LPT 1918 Turbotronn 5L comes with Air brakes

Tata LPT 1918 Turbotronn 5L is available in which all body options ?

Tata LPT 1918 Turbotronn 5L is available in multiple body options of 7380 mm (4225 wb)# 9495 mm (5195 wb)

What is Tata LPT 1918 Turbotronn 5L tyre size and number of wheels in this truck ?

The tyre size of Tata LPT 1918 Turbotronn 5L is 295/90R20 (Tube)# 6+1 tyres

What is the fuel tank capacity of Tata LPT 1918 Turbotronn 5L ?

Tata LPT 1918 Turbotronn 5L comes with Diesel fuel option and its fuel tank capacity is 365 Litres# 365+365 Litres (32 ft)# Polymer tank# With anti-fuel theft

What is the EMI of Tata LPT 1918 Turbotronn 5L ?

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Tata LPT 1918 Turbotronn 5L is expected to be around Rs 47381 for a 5 year period
