Tata 510 LPT BS6 truck specifications

Name: Tata 510 LPT
Brand: Tata
SKU: TBN-20-8310B5

Rate This Vehicle

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers for this month

Download Tata 510 LPT Truck Brochure

Check out the Tata 510 LPT Truck PDF brochure at TrucksBuses.com with all features and specifications.

Key Details of Tata 510 LPT Truck

Power

100

GVW

5490 Kg

Fuel

Diesel

Engine

2956 cc

Cylinders

Engine
4SPCR
Fuel Injection System
Common Rail
Engine Displacement
2956 cc
Engine Cylinders
4
Power
100 HP@2800 rpm
Torque
300 Nm@1200-2200 rpm
Clutch
280 mm dia
With clutch booster
Transmission
5 speed (5F+1R)
Gearbox
G400, Synchromesh
Max Speed
80 Kmph
Emission Norms Compliance
BS6
Fuel Type
Diesel
Fuel Tank Capacity
Diesel: 60 Litres
Ad Blue: 18 Litres
Electricals Battery
12V, 100 Ah
Alternator: 75 Amps

GVW
5490 Kg
Vehicle Configuration
Cabin chassis with PTO
Cabin with load body
Load Body Options
Fixed Side Deck
High Side Deck
Loading Span
10.07 ft
Cabin Type
Day cab
Cabin Tilt mechanism
Manually tiltable
Chassis Frame
Ladder type with cross members
Axle Configuration
4x2
Front Axle
Forged I Beam, Reverse Elliot Type
Rear Axle
Banjo type
Front Suspension
Semi elliptical leaf springs
With telescopic shock absorbers
Rear Suspension
Semi elliptical leaf springs
Tyres
4+1 tyres

Tata 510 LPT Truck Specification Highlights

Check all the Tata 510 LPT specifications on TrucksBuses in the table above The main driveline of this Tata truck includes a 2956 cc 4 cylinder engine that produces a maximum power of 100 HP and a torque of 300 Nm It gets mated to 5 speed (5F+1R), G400, Synchromesh gearbox A gross weight of 5490 kg and multiple configurations allows the owner to carry multiple kinds of goods as per requirement There are multiple features in this Tata truck for enhancing driver comfort Other Tata 510 LPT truck specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the tables above.

Tata 510 LPT Truck Brochure

Download Tata 510 LPT Truck brochure online. Check out the Tata 510 LPT Truck PDF brochure at TrucksBuses.com with all features and specifications.

Frequently Asked Questions on Tata 510 LPT Truck

What is the warranty offered in Tata 510 LPT ?

Tata 510 LPT truck comes with a standard warranty of 3 Years / 3 Lakh Km on driveline

What is the Tata 510 LPT GVW tonnage capacity ?

GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Tata 510 LPT GVW is 5490 Kg

What is the engine capacity of Tata 510 LPT ?

Tata 510 LPT comes with 4 cylinder 4SPCR engine and the engine displacement is 2956 cc

What is Tata 510 LPT power and torque ?

In terms of performance, Tata 510 LPT produces a maximum power of 100 HP@2800 rpm and a maximum torque of 300 Nm@1200-2200 rpm

What is the gearbox and transmission type in Tata 510 LPT ?

Tata 510 LPT comes with a 5 speed (5F+1R) transmission along with a 280 mm dia# With clutch booster clutch

What is the fuel tank capacity of Tata 510 LPT ?

Tata 510 LPT comes with Diesel fuel option and its fuel tank capacity is Diesel: 60 Litres# Ad Blue: 18 Litres

What is Tata 510 LPT tyre size and number of wheels in this truck ?

The tyre size of Tata 510 LPT is 4+1 tyres

What is the type of brakes offered in Tata 510 LPT ?

Tata 510 LPT comes with Hydraulic brakes# With auto slack adjuster# With booster
