Tata 1512g LPT CNG truck specifications

Name: Tata 1512g LPT CNG
Brand: Tata
SKU: TBN-20-C97707

Rate This Vehicle

From ₹ 27.41-29.44 Lakh*
*Ex-showroom Price

Check Discount Offer Check On Road Price

Don't miss out on the best discount offers for this month

Download Tata 1512g LPT CNG Truck Brochure

Check out the Tata 1512g LPT CNG Truck PDF brochure at TrucksBuses.com with all features and specifications.

Key Details of Tata 1512g LPT CNG Truck

Power

125

GVW

16020 Kg

Fuel

CNG

Engine

3783 cc

Cylinders

Key Specifications of Tata 1512g LPT CNG Truck

Engine
Configuration

Engine
3.8L SGI TC
Engine Displacement
3783 cc
Engine Cylinders
4
Power
125 HP@2250 rpm
Torque
420 Nm@1400-1600 rpm
Clutch
330 mm dia
Transmission
5 speed (5F+1R)
Gearbox
GBS 40
Gradeability
25%
Max Speed
80 Kmph
Emission Norms Compliance
BS6
Fuel Type
CNG
Fuel Tank Capacity
650 Litres+
Electricals Battery
12V, 100 Ah
Alternator: 120 Amps

GVW
16020 Kg
Payload
10.1 tons +
Vehicle Configuration
Cabin chassis
Cabin with load body
Load Body Options
Fixed Side Deck
High Side Deck
Loading Span
20 ft
22 ft
24 ft
Cabin Type
Day cab
Cabin Tilt mechanism
Hydraulically tiltable
Chassis Frame
Ladder type with cross members
Axle Configuration
4x2
Front Axle
Forged I Beam, Reverse Elliot Type
Front Suspension
Parabolic leaf springs
With telescopic shock absorbers
Rear Suspension
Semi elliptical leaf springs
Tyres
9R20- 16 PR
Radial tyres
6+1 tyres
Wheelbase
4200 mm
4830 mm
5170 mm
Turning Circle Diameter
16.6 m (4200 wb)
19.2 m (4830 wb)
Ground Clearance
225 mm
Overall Length
7995 mm (4200 wb)
8705 mm (4800 wb)
Overall Height
3200 mm
Load Body Width
2425 mm
Front Track
1950 mm
Rear Track
1809 mm
Chassis Thickness
7 mm

Tata 1512g LPT CNG Truck Specification Highlights

Check all the Tata 1512g LPT CNG specifications on TrucksBuses in the table above The main driveline of this Tata truck includes a 3783 cc 4 cylinder engine that produces a maximum power of 125 HP and a torque of 420 Nm It gets mated to 5 speed (5F+1R), GBS 40 gearbox A gross weight of 16020 kg and multiple configurations allows the owner to carry multiple kinds of goods as per requirement There are multiple features in this Tata truck for enhancing driver comfort Other Tata 1512g LPT CNG truck specifications like chassis, tyre, axle, turning circle dia, engine cc, gradeability are available here in the tables above.

Tata 1512g LPT CNG Truck Brochure

Download Tata 1512g LPT CNG Truck brochure online. Check out the Tata 1512g LPT CNG Truck PDF brochure at TrucksBuses.com with all features and specifications.

Frequently Asked Questions on Tata 1512g LPT CNG Truck

What is the warranty offered in Tata 1512g LPT CNG ?

Tata 1512g LPT CNG truck comes with a standard warranty of 3 Years / 3 Lakh Km on driveline

What is the gearbox and transmission type in Tata 1512g LPT CNG ?

Tata 1512g LPT CNG comes with a 5 speed (5F+1R) transmission along with a 330 mm dia clutch

What is the EMI of Tata 1512g LPT CNG ?

The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Tata 1512g LPT CNG is expected to be around Rs Not Available for a 5 year period
