Overview of Tata Ace HT

Payload 710 Kg
Power (Max.) 16 HP@3200 rpm
Torque (Max.) 37.5 Nm@2000 rpm
Load Body Dimensions (LXWXH) 2140 X 1430 X 300 mm
Warranty 2 years / 72,000 Km
Service Interval 10,000 Km

Engine & Performance of Tata Ace HT

Engine Naturally Aspirated, Indirect Injection
Engine Displacement 702 cc
Engine Cylinders 2
Power (Max.) 16 HP@3200 rpm
Torque (Max.) 37.5 Nm@2000 rpm
Clutch Single plate dry clutch
Transmission 4 speed manual (4F+1R)
Gearbox
  • Synchromesh (Forward)
  • Sliding Mesh (Reverse)
Gradeability 21%
Max Speed 60 Kmph
Emission Norm Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity 30 Litres

Design & Configuration of Tata Ace HT

GVW 1550 Kg
Payload 710 Kg
Vehicle Configuration Cabin with Fixed Side Deck body
Seating Capacity D+1
Axle Configuration 4x2
Front Suspension Rigid axle with parabolic leaf spring
Rear suspension
  • Parabolic leaf spring
  • With hydraulic telescopic shock absorbers
Anti-roll bar No
Tyres 145 R 12 LT 8PR
Wheelbase 2100 mm
Turning Circle Radius 4.3 m
Ground Clearance 160 mm
Overall Length 3800 mm
Overall Width 1500 mm
Overall Height 1845 mm
Front Track 1300 mm
Rear Track 1320 mm
Load Body Dimensions (LXWXH) 2140 X 1430 X 300 mm

Features & Comfort in Tata Ace HT

Steering Type Mechanical type
Steering Adjustment No
Driver Seat Type Standard seat with high head rest
Air Conditioner (A/C) No
Mobile Charging Point Yes
Bottle Holder Yes
Magazine Holder Yes
Additional Digital Clock

Safety in Tata Ace HT

Service Brakes
  • Front: Hydraulic Disc
  • Rear: Hydraulic Drum
Parking Brakes Cable operated acting on Rear Wheels
Anti-Roll Bar No
Seat Belts Yes
Tubeless Tyres No
