Overview of Tata Xenon Yodha

Payload 1250 Kg
Power (Max.) 85 HP@3000 rpm
Torque (Max.) 250 Nm@1000-2000 rpm
Load Body Dimensions (LXWXH) 2550 x 1750 x 415 mm
Warranty 3 years / 3 Lakh Km
Service Interval 20,000 Km

Engine & Performance of Tata Xenon Yodha

Engine Tata 4SPCR TCIC
Engine Displacement 2956 cc
Engine Cylinders 4
Power (Max.) 85 HP@3000 rpm
Torque (Max.) 250 Nm@1000-2000 rpm
Clutch
  • Single plate dry clutch
  • 260 mm dia
Transmission 5 speed Manual (5F+1R)
Gearbox GBS76 - 5/4.1 Synchromesh
Gradeability 30%
Max Speed 80 Kmph
Emission Norm Compliance BSIV
Fuel Type Diesel
Fuel Tank Capacity 45 Litres

Design & Configuration of Tata Xenon Yodha

GVW 3100 Kg
Payload 1250 Kg
Vehicle Configuration
  • Cabin with Fixed Side Deck body
  • Cabin with Drop Side Deck body
Seating Capacity
  • D+1
  • Joint laydown seat for sleeping purpose
Axle Configuration 4x2
Front Suspension Semi-elliptical leaf spring
Rear suspension
  • Semi elliptical leaf spring
  • 2 stage
Anti-roll bar Front only
Tyres 215/75 R16 radial
Wheelbase 3150 mm
Turning Circle Radius 6.25 m
Ground Clearance 210 mm
Overall Length 5350 mm
Overall Width 1860 mm
Overall Height 1810 mm
Load Body Dimensions (LXWXH) 2550 x 1750 x 415 mm

Features & Comfort in Tata Xenon Yodha

Steering Type Power Steering
Steering Adjustment Tiltable and telescopic
Driver Seat Type Standard seat with high head rest
Air Conditioner (A/C) No
Mobile Charging Point Yes
Bottle Holder Yes

Safety in Tata Xenon Yodha

Service Brakes
  • Front: Hydraulic Disc, twin pot
  • Rear: Hydraulic Drum
Anti-Roll Bar Front only
Seat Belts Yes
Tubeless Tyres No
