Tata Ace Gold Diesel Plus High Deck Mini Truck Specifications

Rate This Vehicle

From ₹ 6.25 Lakh* Onwards
*Ex-showroom Price

Check Discount Offer Check On Road Price
 Don't miss out on the best discount offers for this month

Key Details of Tata Ace Gold Diesel Plus High Deck Mini Truck

Power
Power
GVW
1675 Kg
Fuel
Diesel
Engine
702 cc
Cylinders
2
Trucksbuses.com
Trucksbuses.com

Key Specifications of Tata Ace Gold Diesel Plus High Deck Mini Truck

  • Engine
    DI Turbocharged engine
    SCR technology
  • Engine Displacement
    702 cc
  • Engine Cylinders
    2
  • Power
    22 HP
  • Torque
    55 Nm
  • Clutch
    Single plate dry clutch
  • Transmission
    5 speed (5F+1R)
  • Gearbox
    GBS 65 Synchromesh
  • Gradeability
    27.50%
  • Max Speed
    60 Kmph
  • Emission Norms Compliance
    BS6 OBD2
  • Fuel Type
    Diesel
  • Fuel Tank Capacity
    Diesel: 30 Litres
    DEF: 10.5 Litres
  • GVW
    1510 Kg
  • Payload
    750 Kg
  • Vehicle Configuration
    Cabin with High Deck body
  • Seating Capacity
    D+1
  • Axle Configuration
    4x2
  • Front Suspension
    Rigid axle with parabolic leaf spring
  • Rear Suspension
    Semi elliptical leaf spring
  • Anti Roll Bar
    No
  • Tyres
    145 R 12 LT 8PR
  • Wheelbase
    2100 mm
  • Turning Circle Diameter
    8.6 m
  • Ground Clearance
    160 mm
  • Overall Length
    3800 mm
  • Overall Width
    1500 mm
  • Overall Height
    1845 mm
  • Front Track
    1300 mm
  • Rear Track
    1320 mm
  • Load Body Dimensions
    7.2 x 4.9 ft

Tata Ace Gold Diesel Plus High Deck Mini Truck Specification Highlights

Tata Ace Gold Diesel Plus High Deck is equipped with a 2-cylinder DI Turbocharged engine with 702 cc displacement and it generates maximum power and maximum torque. Tata Ace Gold Diesel Plus High deck mini truck comes with a 5-speed gearbox and 4*2 axle configuration to make drive smooth. Tata Ace Gold Diesel Plus High Deck offers superior mileage with fuel affection and a big fuel tank capacity of 30 litres and 10.5 litres of polymer, and it can travel miles without refuelling. Tata Ace Gold Diesel Plus High Deck comes with a wheelbase of 2100 mm and an optimum 3800 mm overall vehicle length, and its turning circle diameter is 8.6 m and suspension in front and rear allows it to carry multiple loads easily. Tata Ace Gold Diesel Plus High Deck offers a superior 160 mm ground clearance.

Frequently Asked Questions on Tata Ace Gold Diesel Plus High Deck Mini Truck

Tata Ace Gold Diesel Plus High Deck price starts from Rs 6.25 Lakh* Onwards . The 2023 price of Tata Ace Gold Diesel Plus High Deck can vary slightly from state to state and city to city.
GVW of any truck is the sum total of empty kerb weight and the payload it can carry. Tata Ace Gold Diesel Plus High Deck GVW is 1510 Kg
Payload defines the loading capacity of any truck. The payload of Tata Ace Gold Diesel Plus High Deck is 750 Kg
Tata Ace Gold Diesel Plus High Deck comes with 2 cylinder DI Turbocharged engine# SCR technology engine and the engine displacement is 702 cc
In terms of performance, Tata Ace Gold Diesel Plus High Deck produces a maximum power of 22 HP and a maximum torque of 55 Nm
Tata Ace Gold Diesel Plus High Deck comes with a 5 speed (5F+1R) transmission
Tata Ace Gold Diesel Plus High Deck comes with Diesel fuel option and its fuel tank capacity is Diesel: 30 Litres# DEF: 10.5 Litres
Gradeability of any truck defines its ability to climb upward slopes. The gradeability of Tata Ace Gold Diesel Plus High Deck is 27.50%.
The monthly EMI of any truck depends on the interest rate offered by bank, down payment made by the buyer and the loan tenure. Considering a 10% down payment and 9.5% rate of interest, the EMI of Tata Ace Gold Diesel Plus High Deck is expected to be around Rs Not Available for a 5 year period
The tyre size of Tata Ace Gold Diesel Plus High Deck is 145 R 12 LT 8PR
