Compare Volvo 9400 12M vs Ashok Leyland Freedom 12M FE: 177 HP

Compare volvo 9400 12m vs ashok leyland freedom 12m fe 177 hp


https://res.cloudinary.com/dz4x78ghb/image/fetch/c_scale,q_30,w_300,f_auto/https://www.trucksbuses.com/uploads/Volvo 9400 Intercity Coach78.jpg

Volvo 9400 12M

https://res.cloudinary.com/dz4x78ghb/image/fetch/c_scale,q_30,w_300,f_auto/https://www.trucksbuses.com/uploads/459_04afeabf381f483f88c09014b7b0af1cAshok_Leyland_12m_FE_Intercity_Bus_Coach_1_-removebg-preview.png

Ashok Leyland Freedom 12M FE: 177 HP

  • Overviewof volvo 9400 12m vs ashok leyland freedom 12m fe 177 hp

  • Power
    330 HP@2200 rpm
    177 HP@2400 rpm
  • Torque
    1200 Nm@1200-1600 rpm
    660 Nm@1200-1900 rpm
  • Engine
    D8C 330 Common Rail
    Turbocharged, Intercooled
    H Series CRS
    iEGR Technology
  • GVW (Kg)
    43+D
    38+D; 40+D; 41+D
  • GVW (Kg)
    16200 Kg
    16200 Kg
  • Warranty
    4 Years / 4 Lakh Km on driveline
  • Service Interval
    80,000 Km (Oil change)
  • Engine & Performanceof volvo 9400 12m vs ashok leyland freedom 12m fe 177 hp

  • Engine
    D8C 330 Common Rail
    Turbocharged, Intercooled
    H Series CRS
    iEGR Technology
  • Power
    330 HP@2200 rpm
    177 HP@2400 rpm
  • Torque
    1200 Nm@1200-1600 rpm
    660 Nm@1200-1900 rpm
  • Fuel Injection System
    Common Rail
    Common rail
  • Displacement
    7700 cc
    5660 cc
  • Cylinders
    6
    6
  • Engine Location
    Rear
    Front
  • Transmission
    6 speed manual (6F+1R)
    6 speed manual (6F+1R)
  • Gearbox
    Synchromesh
    Synchromesh
  • Clutch
    380 Diaphragm type
    With clutch booster
  • Gradeability
    33.50%
  • Max Speed
    80 Kmph
    80 Kmph
  • Emission
    BSIV
    BSIV
  • Fuel Type
    Diesel
    Diesel
  • Fuel Tank
    450 Litres
    2 tanks of 300+150 Litres
    350 Litres
  • Battery
    2x12V, 165 Ah
    Alternator: 2x110 A
    24V, 200 Ah
    Alternator: 85 A
  • Design & Configurationof volvo 9400 12m vs ashok leyland freedom 12m fe 177 hp

  • GVW
    16200 Kg
    16200 Kg
  • Seating Layout
    2x2
    2x2
  • Seating Capacity
    43+D
    38+D; 40+D; 41+D
  • Axle Configuration
    4x2
    4x2
  • Chassis Frame
    All steel, ladder type
    All steel ladder type, Bolted construction
  • Body Structure
    Galvanized tubular structure
  • Passenger Door Type
    Pneumatically operated
    Pneumatically operated
  • Floor Type
    Boiling water proof ply + FR grade
  • Front Axle
    Rigid type
    Rigid type
  • Rear Axle
    Fully floating
  • Front Suspension
    Independent air suspension
    Electronically controlled
    Rubber ended leaf spring
    Air suspension (Optional)
  • Rear Suspension
    Air suspension
    Semi elliptical leaf spring
    Air suspension (Optional)
  • Anti Roll Bar
    Front and rear axle
  • Tyres
    295/80 R 22.5
    Tubeless radial
    6+1 tyres
    10R20 tube radials
    295/80 R 22.5 tubeless (optional)
    6+1 tyres
  • Wheelbase
    6200 mm
    6200 mm
  • Turning Circle Diameter
    20.5 m
  • Ground Clearance
    190 mm
  • Overall Length
    12000 mm
    12000 mm
  • Overall Width
    2600 mm
  • Overall Height
    3600 mm
  • Front Overhang
    2620 mm
    2400 mm
  • Rear Overhang
    3210 mm
    3400 mm
  • Front Track
    2054 mm
    1963 mm
  • Rear Track
    1837 mm
    1816 mm
  • Floor Height
    1150 mm
  • Features & Comfortof volvo 9400 12m vs ashok leyland freedom 12m fe 177 hp

  • Steering Type
    Power Steering
    With steering lock
    Power Steering
  • Steering Adjustment
    Tilt and Telescopic
    Rigid
  • Instrument cluster
    Digital instrument cluster
    Analog
    With LED display
  • Automatic Transmission
  • Air Conditioner AC
  • Quarter Ventilation Glass
  • Sun Visor
    Roll down type
  • Front Windshield
    Single piece laminated glass
    Single piece laminated glass
  • Rear Windshield
    Single piece, toughened
    Single piece, toughened
  • Side Windows
    Single piece, toughened
    Single piece, toughened
  • Hatrack
    Modular
    Modular
  • Passenger Seat Type
    Reclining without calf support
    Reclining
  • Arm Rests
    Available on each seat
    Available on each seat
  • AC Vents
    Individual adjustable
    Integrated in hatrack
    Individual adjustable
    Integrated in hatrack
  • Mobile Charging Point
  • Bottle Holder
  • Music System
  • Luggage Space
    Side luggage boot; 10 Cu.M luggage space
    Side luggage boot; 8 Cu.M luggage space
  • Saloon Light
    LED lights
  • Step Lamp
  • Safetyof volvo 9400 12m vs ashok leyland freedom 12m fe 177 hp

  • Service Brakes
    Full-air Disc brakes
    Electronic Braking System (EBS)
    Electronic Stability Program (ESP)
    Air brakes dual line
  • Parking Brakes
    Air operated acting on rear wheels
    Flick Valve operated on rear wheels
  • ABS
  • Seat Belts
    Optional
  • Window Guardrail
    NA
    NA
  • Driver Partition
    Fixed
  • Emergency Exit
  • Roof Hatch
    Yes, 2 numbers
  • Fire Extinguisher
  • First Aid Box
  • Peep Window
    NA
  • Fog Light
  • Anti Roll Bar
    Front and rear axle
  • Tubeless Tyres
    Optional
  • Retarder
    Hydrodynamic retarder
    Electromagnetic retarder (optional)
  • Step Lamp

Key Comparison of Volvo 9400 12M vs Ashok Leyland Freedom 12M FE: 177 HP

Compare Volvo 9400 12M bus vs Ashok Leyland Freedom 12M FE: 177 HP bus in detail at TrucksBuses.com ! Volvo 9400 12M bus with 7700 cc H Series CRS# iEGR Technology engine gives a power of 330 HP@2200 rpm whereas Ashok Leyland Freedom 12M FE: 177 HP bus produces 177 HP@2400 rpm of power and comes with a 5660 cc engine. The fuel tank capacity of Volvo 9400 12M bus is 450 Litres# 2 tanks of 300+150 Litres whereas Ashok Leyland Freedom 12M FE: 177 HP bus is 350 Litres. You can check detailed bus comparison of Volvo 9400 12M bus and Ashok Leyland Freedom 12M FE: 177 HP bus on the basis of engine, specifications, seating capacity, price, mileage and features.
